# Basic Features

# Browsing and Operating Models

Users can utilize the toolbar on the right side of the WeBIMSync interface to manipulate their position within the model scene. The toolbar includes the following functionalities: Select, Walk, Look Around, Zoom, Zoom Box, Pan, Constrained Orbit, Measure, Shortest Distance between Two Objects, Markups, Section, Drawing Viewer, Elevation, Default Viewpoint, and Camera

Left Middle Right
Select Select model objects N/A Open context menu
Walk Hold and move to walk Hold: Adjust view along line of sight
Scroll: Adjust vertical angle
N/A
Look Around Hold to rotate view N/A N/A
Zoom Zoom in/out Zoom in/out view N/A
Zoom Box Drag to zoom into a selected area Zoom in/out view N/A
Pan Hold to pan the view Zoom in/out view N/A
Constrained Orbit Rotate around an axis Hold: Pan view
Scroll: Adjust vertical angle
Set axis center

Drawing Viewer: Use with drawings to view the selected plan.

Elevation: Show the elevation at the cursor's position.

Default Viewpoint: Automatically switch to the initial model view.

# Measure

# Steps

  1. Click the [ Measure ] button.

  2. Click two points within the model to measure the distances along the three axes.

  3. Right-click to remove the measurement results after completion.

TIP

Measurement units can be customized in Settings.

# Shortest Distance Between Two Objects

# Steps

  1. Use the [ Select ] tool to select the first object.

  2. Hold down the [ Ctrl ] key on your keyboard and select the second object.

  3. After selecting both objects, click on the [ Shortest Distance Between Two Objects ] button on the toolbar to display the measurement.

  4. Click the button again to close the measurement result.

# Section

# Steps

  1. Click on the [ Section ] button.

  2. Drag the scrollbars in six directions to create cross-sectional views of the model in a 3D workspace.

TIP

For detailed control, hover over the scrollbar and use the mouse wheel, keyboard arrow keys (up/down), or type numerical values for precise adjustments.

# Screenshot

Click the [ Screen Capture ] button in the toolbar to quickly capture the current model view and save it as an image file for documentation or sharing.

# Camera

The camera functionality can be activated on devices equipped with a camera. Click on the [ Camera ] button to enable virtual-to-real comparison, enhancing communication efficiency. For further details, please refer to the Camera and Comparison Mode section.

TIP

The camera button will not be visible if the system does not detect an available camera device.
